Details

Please Note, this product is not for consumer use in the European Union.

Intuitive LCD interface

Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.

Predictive replace battery date

Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.

Green mode

Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.

Energy meter

Provides actual kilowatt hours of usage for energy conscious users.

Pure sine wave output on battery

Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.

High online efficiency

Reduces utlility costs, generates less heat.

SmartSlot

Customize UPS capabilities with management cards.

Cold-start capable

Provides temporary battery power when the utility power is out.

Temperature-compensated battery charging

Prolongs battery life by regulating the charge voltage according to battery temperature.

AC outlet types	C13 coupler
AC outlets quantity	6 AC outlet(s)
Battery capacity	146 VAh
Battery recharge time	3 h
Battery technology	Sealed Lead Acid (VRLA)
Cable length	1.83 m
Cables included	RS-232,USB cable
Certification	CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, UL 1778, VDE, REACH, PEP, EOLI
Colour of product	Black
Depth	358 mm
Dimensions (WxDxH)	161 x 138 x 363 mm
Display	LCD
Efficiency	98 %
Ethernet LAN (RJ-45) ports quantity	1
Form factor	Tower
Height	157 mm
Hot-swap battery	Yes
Input connection type	IEC-320 C14
Input operation voltage (max)	302 V
Input operation voltage (min)	151 V
LED indicators	Status
Noise level	40 dB
Nominal input voltage	230 V
Nominal output voltage	230 V
Non-operating altitude	0 - 15000 m
Operating altitude	0 - 3000 m
Operating relative humidity (H-H)	5 - 95 %
Operating relative humidity range	5 - 95 %
Operating temperature (T-T)	0 - 40 °C
Operating temperature range (T-T)	0 - 40 °C
Output connections	6 x IEC 320 C13
Output operation voltage (max)	240 V
Output operation voltage (min)	220 V
Output power	500 W
Output power capacity (VA)	750 VA
Output voltage note	220/230/240
Package dimensions (WxDxH)	301 x 278 x 499 mm
Package height	301 mm
Package weight	14230 g
Package width	278 mm
Power supply input frequency	50/60 Hz
Quantity per pallet	24 pc(s)
Quick installation guide	Yes
Replacement battery cartridge	RBC48
RoHS compliance	Yes
Serial ports quantity	1
Source data-sheet	Icecat.biz
Storage relative humidity (H-H)	0 - 95 %
Storage relative humidity range	5 - 95 %
Storage temperature (T-T)	-15 - 45 °C
Storage temperature range (T-T)	-15 - 45 °C
Surge energy rating	540 J
Typical backup time at full load	4.6 min
Typical backup time at half load	15.8 min
USB port	Yes
Waveform	Sine
Weight	13180 g
Width	138 mm
