Features:
- Local and Remote Units connect at distances up to 150 m using Cat 5e cable.
- Dual console operation - control your system from both the local and remote USB keyboard, monitor, and mouse consoles.
- Built-in ASIC for greater reliability and compatibility.
- USB Keyboard and USB Mouse Ports.
- RS-232 serial ports - allows you to connect to a serial terminal for configuration (Local Unit), or serial devices such as touchscreens and barcode scanners (Remote Unit).
- Supports stereo speakers and stereo microphone.
- USB overcurrent detection and prevention.
- Pushbutton operating mode selection (Local Unit only) -select between Local and Auto operating modes.
- Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection.
- Adjustable gain control - manually adjusts signal strength to compensate for distance.
- High resolution video - up to 1600 x 1200 @ 60 Hz (150 m); 1280 x 1024 @60 Hz (200 m).
-Supports VGA, SVGA, SXGA (1280 x 1024) and UXGA (1600 x 1200) and multisync monitors; local monitor supports DDC; DDC2; DDC2B.
- Hot pluggable.
- Rack mountable.
- Easy to install - no software required - connecting cables to the devices is all it takes.
- Multiplatform support - Windows 2000/XP/Vista, Linux, FreeBSD.
Package Contents
- 1x USB KVM Extender (Local Unit)
- 1x USB KVM Extender (Remote Unit)
- 1x USB KVM Cable (1.8 m)
- 2x 0AD6-1605-24EG Power Adapters
- 1x Mounting Kit
- 1x User Instructions
AC input frequency |
50 - 60 Hz |
Cable length |
1.8 m |
Cables included |
1x USB KVM Extender (Local)
1x USB KVM Extender (Remote)
1x USB KVM Cable (1.8 m)
2x Power Adapters
1x Rack Mount Kit
2x Grounding Wires |
Colour of product |
Grey |
Connectivity technology |
Wired & Wireless |
Dimensions (WxDxH) |
200 x 80 x 25 mm |
Headphone outputs |
1 |
I/O ports |
2 x USB Type A Female
1 x HDB-15 Female
2 x Mini Stereo Jack Female
1 x DB-9 Female
1 x DB-9 Male
1 x RJ-45 Female
1 x DC Jack
1 x SPHD-15 Female
2 x Mini Stereo Jack Female
|
Keyboard port type |
USB |
LED indicators |
Yes |
Operating temperature range (T-T) |
0 - 50 °C |
Power supply type |
DC5.3V/DC5.3 |
Size |
12700 mm (500 ") |
Source data-sheet |
Icecat.biz |
Speaker/ headphone/ line-out jack |
1 |
Storage relative humidity range |
0 - 80 % |
Storage temperature range (T-T) |
-20 - 60 °C |
Technical features |
1920x1200@60Hz - 30m
1600x1200@60Hz - 150m
1280x1024@60Hz - 200m |
Weight |
490 g |
Specific References
- EAN13
- 0672792100604
