Resettable circuit breaker

Easy recovery from overloads; no need to replace a fuse.

Audible alarms

Provides notification of changing utility power and UPS power conditions

Automatic self-test Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Battery-protected and surge-only outlets

Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment.

Battery failure notification

Provides early-warning fault analysis on batteries enabling timely preventive maintenance

Safety-agency approved

Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.

User-replaceable batteries

Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR).

Battery and surge protected outlets

Back up and protect your hardware and data during power outages, surges and spikes.

Surge only outlets

Protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage.

Automatic self-test

Periodic battery self-test ensures early detection of a battery that needs to be replaced.

Battery failure notification

Provides early-warning fault analysis on batteries enabling timely preventive maintenance.

Intelligent battery management

Maximizes battery performance, life, and reliability through intelligent, precision charging.

Resettable circuit breaker

Easy recovery from overloads; no need to replace a fuse.

Audible alarms

Provides notification of changing utility power and UPS power conditions.

LED status display

Quickly understand unit and power status with visual indicators.

AC outlet types	BS 1363
AC outlets quantity	8 AC outlet(s)
Battery recharge time	16 h
Battery technology	Sealed Lead Acid (VRLA)
Cable length	1.83 m
Certification	BSI 1363
Colour of product	Charcoal
Depth	285 mm
Dimensions (WxDxH)	230 x 285 x 86 mm
Filtering	Yes
Form factor	Compact
Height	86 mm
Input connection type	BS1363A
Input operation voltage (max)	230 V
Input operation voltage (min)	230 V
LED indicators	Yes
Networking features	RJ-45 Modem/Fax/DSL/10-100 Base-T
Noise level	45 dB
Nominal input voltage	230 V
Nominal output voltage	230 V
Non-operating altitude	0 - 15000 m
Operating altitude	0 - 15000 m
Operating relative humidity (H-H)	0 - 95 %
Operating relative humidity range	0 - 95 %
Operating temperature (T-T)	0 - 40 °C
Operating temperature range (T-T)	0 - 40 °C
Output connections	4x BS 1363 (Battery Backup) 4x BS 1363 (Surge Protection)
Output operation voltage (max)	230 V
Output operation voltage (min)	230 V
Output power	240 W
Output power capacity (VA)	400 VA
Package dimensions (WxDxH)	300 x 366 x 132 mm
Package height	132 mm
Package weight	5600 g
Package width	300 mm
Power supply input frequency	50/60 Hz
RoHS compliance	Yes
Source data-sheet	Icecat.biz
Storage relative humidity (H-H)	0 - 95 %
Storage relative humidity range	0 - 95 %
Storage temperature (T-T)	0 - 40 °C
Surge energy rating	310 J
Surge protection features	Network,Telephone
Typical backup time at full load	5.2 min
Typical backup time at half load	18.1 min
Weight	5400 g
Width	230 mm
